Build a blazingly fast transactional database with the R630 24 all-flash drive configuration. Combine the density, scalability and performance of 24 x 1.8" SSDs with dual-PERC capability to deliver a superior solution that can boost performance by storing an entire database. When combined with the SanDisk® DAS Cache solution, the R630 can help increase OLTP transactions and concurrent usage for latency-sensitive applications, such as e-commerce or financial trading.
The Dell EMC OpenManage™ portfolio helps deliver peak efficiency for PowerEdge servers, delivering intelligent, automated management of routine tasks. Combined with unique agent-free management capabilities, the R640 is simply managed, freeing up time for high profile projects.
• Simplify management with the OpenManage Enterprise™ console, with customized reporting and automatic discovery.
• Take advantage of QuickSync 2 capabilities and gain access to your servers easily through your phone or tablet
Quickly and securely monitor or modify critical server settings “at the box” with the iDRAC Quick Sync bezel with embedded near field communication (NFC) capability. Use a handheld device with the bezel to quickly check system health details, and use iDRAC Direct to easily deploy or modify settings across multiple servers with a USB key or laptop, eliminating the potential for configuration errors
System overview
The Dell™ PowerEdge™ R630 is Dell’s latest 2-socket, 1U rack server designed to run complex
workloads using highly scalable memory, I/O capacity and flexible network options. The R630
features the Intel®
Xeon®
processor E5-2600 v3 product family, up to 24 DIMMs, PCI Express®
(PCIe)
3.0 enabled expansion slots, and a choice of NIC technologies.
The PowerEdge R630 is a general-purpose platform with highly expandable memory (up to 768GB)
and impressive I/O capabilities to match. The R630 can readily handle very demanding workloads,
such as data warehouses, e-commerce, virtual desktop infrastructure (VDI), databases and high performance computing (HPC).
The R630 brings a new dimension to dense rack servers with up to 24 x 1.8” solid-state drives (SSD)
available in a single 1U chassis. The 24 drives can be zoned to add a second Dell PowerEdge RAID
Controller (PERC) controller for maximum IOPS performance.
Chassis views
The R630 has three chassis options: 8 x 2.5” drives, 10 x 2.5” drives or 24 x 1.8” drives. A chassis cannot be reconfigured or upgraded after point of purchase. Other features on the front panel include an interactive LCD control panel, USB management port, video connector and vFlash media card slot.
Figure 1 is the front view of the R630 chassis with 8 x 2.5” hard drives.
Figure 1. 8-drive bay chassis front view without bezel
Figure 2 is the front view of the R630 chassis with 10 x 2.5” hard drives.
Figure 2. 10-drive bay chassis front view without bezel
Figure 3 is the front view of the R630 chassis with 24 x 1.8” hard drives.
Figure 3. 24-drive bay chassis front view without bezel
Figure 4 shows the optional bezel on the front of an 8-drive bay chassis. The bezel for the 10-drive bay chassis is different than the bezel for the 8-drive bay chassis.
Figure 4. Front view with bezel
Figure 5 shows the R630 back panel of the 8-drive bay chassis with 3 PCIe slots. Features on the back panel include the system identification light and button, iDRAC8 Enterprise port (activated only when iDRAC8 Enterprise is installed), serial connector, video connector, USB connectors, Ethernet connectors and power supplies.
Figure 5. Back view
Figure 6 is an internal view of the R630 24-drive bay system including fans, DIMMs, power supplies, system board and hard drive bays.
Figure 6. 24-drive 1.8” bay chassis internal view
