Product Details:
|
| Type: | Network Switch | Processor: | 48 X 10 Gig SFP+, 6 X 40/100 Gig QSFP28 |
|---|---|---|---|
| Chassis Height(U): | 1U | Dimensions (W X D X H): | 550 Mm X 180 Mm X 650 Mm |
| Switching Capacity: | 2.16/2.4 Tbit/s | Weight: | 8.5kg |
| Highlight: | CloudEngine 10gb poe switch,Huawei 10gb poe switch,S6730-H48X6C |
||
| Fixed ports | 48 x 10 Gig SFP+, 6 x 40/100 Gig QSFP28 |
| Dimensions (W x D x H) | 442 mm x 420 mm x 43.6 mm |
| Chassis height (U) | 1U |
| Input voltage | AC Power: 100V to 240V AC; 50/60 Hz (Max: 90V to 290V AC; 45-65 Hz) DC Power: -48V to -60V |
| Switching Capacity | 2.16/2.4 Tbit/s |
| Input current | AC 600W: Max 8A DC 1000W: Max 30A |
| Maximum power consumption | 274W |
| Minimum power consumption | 97W |
| ① | Ground screw | ⑦ | Fan module slot 1 |
| ② | SSD card slot | ⑧ | Fan module slot 2 |
| ③ | One console port | ⑨ | Fan module slot 3 |
| ④ | One ETH management port | ⑩ | Fan module slot 4 |
| ⑤ | One USB port | ⑪ | Power module slot 1 |
| ⑥ | One PNP button | ⑫ | Power module slot 2 |
