| ThinkSystem SR670 V2 Rack Server |
Technicial specification |
| Form factor |
2U rack. |
| Processor |
Two second-generation Intel Xeon Processor Scalable processors (formerly codename "Cascade Lake"). Up to 28 cores, core frequencies up to 3.8 GHz, and TDP ratings up to 205W. Two Intel Ultra Path Interconnect (UPI) links at 10.4 GT/s each. |
| Chipset |
Intel C624 "Lewisburg" chipset |
| Memory |
24 DIMM sockets (12 DIMMs per processor) supporting Lenovo TruDDR4 DIMMs at up to 2933 MHz. |
| Memory maximums |
With RDIMMs: Up to 1.5 TB with 24x 64 GB RDIMMs and two processors. |
| Memory protection |
ECC, SDDC (for x4-based memory DIMMs), ADDDC (for x4-based memory DIMMs), memory mirroring, and memory sparing. |
| Disk drive bays |
Eight 2.5-inch hot-swap drive bays supporting SATA HDDs and SSDs. M.2 slot for one or two M.2 drives. |
| Maximum internal storage |
- 245.76TB using 8x 30.72TB 2.5-inch SAS/SATA SSDs
- 16TB using 8x 2TB 2.5-inch HDDs
|
| Storage controller |
- Onboard 6 Gb SATA for simple-swap drive configurations, using embedded Intel RSTe software RAID, supporting RAID 0, 1, 10, 5
- 12 Gb SAS/SATA RAID for hot-swap drive configurations:
- RAID 530i (cacheless) supports RAID 0, 1, 10, 5, 50
- RAID 730-8i with 1GB cache supports RAID 0, 1, 10, 5, 50
- RAID 930-8i with 2GB flash-backed cache supports RAID 0, 1, 10, 5, 50, 6, 60
- RAID 940-8i with 4GB flash-backed cache supports RAID 0, 1, 10, 5, 50, 6, 60
- 12 Gb SAS/SATA non-RAID: 430-8i HBA
|
| Optical drive bays |
No internal optical drive. |
| Tape drive bays |
No internal backup drive. |
| Network interfaces |
None standard; add networking via a PCIe adapter. Dedicated Ethernet port for systems management (connected to the XClarity Controller) is standard. |
| PCI Expansion slots |
- With support for four double-wide GPUs, there are seven front-accessible PCIe slots
- With support for eight-wide GPUs, there are 11 front-accessible PCIe slots
See the I/O expansion options section for details.
|
| Ports |
Front: One USB 2.0 port, one USB 3.0 port, one VGA video port, one RJ45 XClarity Controller (XCC) systems management port.
Rear: One DB9 serial port. The serial port can be redirected and accessed remotely via IPMI or SSH via XCC.
|
| Cooling |
Six N+1 redundant simple-swap 60 mm dual-rotor fans (all six standard). One fan integrated in each power supply. |
| Power supply |
Two 2000W hot-swap AC power supplies with 80 PLUS Platinum certification. Power supplies are redundant in most configurations. Requires 200-240 V AC power (110 V AC not supported). |
| Video |
G200e graphics with 16 MB memory with 2D hardware accelerator, integrated into the XClarity Controller. Maximum resolution is 1920x1200 32bpp at 60Hz. |
| Hot-swap parts |
Drives and power supplies. |
| Systems management |
XClarity Controller embedded systems management. Support for Lenovo intelligent Computing Orchestration (LiCO), Lenovo XClarity Essentials (BoMC, UpdateExpress, OneCLI), Lenovo XClarity Provisioning Manager. Redfish API Spec v1.0.2 compliant. Optional XClarity Controller Advanced or Enterprise with software license upgrade to enable remote control functions. XClarity Administrator and XClarity Energy Manager currently not supported. |
| Security features |
Power-on password, administrator's password, Trusted Platform Module (TPM), supporting TPM 2.0 . In China only, optional Nationz TPM 2.0 plug-in module. |
| Operating systems supported |
Red Hat Enterprise Linux and SUSE Linux Enterprise Server. See the Operating system support section for specifics. |
| Limited warranty |
Three-year or one-year or no warranty (model dependent). Customer-replaceable unit (CRU) and onsite limited warranty with 9x5 next business day (NBD). |
| Service and support |
Optional service upgrades are available through Lenovo Services: 4-hour or 2-hour response time, 6-hour fix time, 1-year or 2-year warranty extension, software support for Lenovo hardware and some third-party applications. |
| Dimensions |
Width: 448 mm (17.6 in.), height: 87 mm (3.4 in.), depth: 906 mm (35.7 in.). See Physical and electrical specifications for details. |
| Weight |
32 kg (71.9 lb) depending on the specific configuration |
