8SFF HPE ProLiant DL325 Gen10 Plus Server AMD EPYC™ 7000 CPU

Description of HPE ProLiant DL325 Gen10 8SFF



The HPE ProLiant DL325 Gen10 8SFF is a single-socket, 1U rack server designed to deliver exceptional performance for virtualization, data analytics, and I/O-intensive applications. Powered by an AMD EPYC processor with up to 64 cores, it provides high compute density and efficient multi-threaded performance in a compact form factor. This model supports up to 8 SFF (Small Form Factor) hot-swappable drive bays, with options for NVMe, SAS, and SATA drives, providing flexible storage configurations and fast data access. With up to 16 DIMM slots and support for up to 2TB of DDR4 memory, the DL325 Gen10 ensures responsive application performance and high memory bandwidth. HPE’s iLO 5 management technology enhances security and remote management, while PCIe 3.0 expansion slots allow for additional connectivity or GPU upgrades. The DL325 Gen10 8SFF is ideal for enterprises seeking a scalable and reliable solution in a compact footprint, offering the power and efficiency needed for modern workloads.

HPE ProLiant DL325 Gen10 Server The HPE ProLiant DL325 Gen10 Server is the secure and versatile single socket server for virtualization and I/O intensive

workloads.

Powered by the latest AMD® EPYC® 7xx2 Series Processors , the HPE ProLiant DL325 Gen10 Server offers greater processing power and faster memory speeds upto 2933 MT/s This 1P, 1U server delivers an exceptional balance of processor, memory and I/O for 2P performance at 1P TCO.

Get the most out of your virtualized environment with this versatile server

1.

1. Quick removal access panel

6. USB 3.0 port

2. Serial no. label pull tab

7. NIC status LED

3. Optional Media Bay*

8. iLO Service Port

4 Power On/Standby button and system power LED

9. UID button/LED

5. Health LED

10. Standard 8 SAS/SATA drive bays

10SFF

1. Quick removal access panel

6. USB 3.0 port

2. Serial no. label pull tab

7. NIC status LED

3. Optional Media Bay*

8. iLO Service Port

4 Power On/Standby button and system power LED

9. UID button/LED

5. Health LED

10. Standard 8 SAS/SATA drive bays

4SFF

1. Quick removal access panel

6. USB 3.0 port

2. Serial no. label pull tab

7. NIC status LED

3. Optional Media Bay*

8. iLO Service Port

4 Power On/Standby button and system power LED

9. UID button/LED

5. Health LED

10. Standard 8 SAS/SATA drive bays

1 Fan cage shown with 5 Performance Hot-swappable fans 8 Hot Plug redundant HPE Flexible Slot Power supplies 2 Optional HPE Smart Storage Battery 9 Optional HPE Flexible Smart Array Controller (P408i-a shown) 3 Hard drive Backplane Power Connector 10 Serial Port Connector 4 Chassis intrusion detection connector 11 (Under) Optional Flexible LOM slot 5 Processor (heatsink shown) 12 Primary PCIe riser, standard 6 DDR4 DIMM slots. Shown fully populated in 16 slots 13 Internal USB 3.0 connector 7 Connection for second (optional) riser 14 MicroSD card slot

1. Slot 1 PCIe 3.0

6 iLO Management Port

2. Slot 2 PCIe 3.0

7 UID LED

3 Optional Slot 3 PCIe 3.0

8 **Embedded 4x 1GbE Adapter ( if equipped)

4. HPE Flexible Slot Power Supply Bay

9 VGA Port

5 USB 3.0 Ports

10 **Option: FlexibleLOM (Shown: 4x 1GbE)
